Self-propelled articulated boom lift GTBZ16SU

diesel

Main spec. ● Max. Working Height：15.60m ● Max. allowable cargo：1350kg ● Max. Horizontal Reach：8.66m Important features ● 4WD and 4WS provides surperior performance and maneuverability ● Automatic leveling platform ● Automatic outriggers ● Chassis Auto-leveling Size Max. Working Height 15.60m Max. Platform Height 13.60m Max. Horizontal Reach 8.66m Maximum Rearward 5.16m Platform Slider Boom 1.80m Overall Length 7.30m Overall Width 2.50m/2.30m Overall Height(Rails Up / Rails Down) 3.66/2.62m Platform Size(Lengt / Wide 6.70×2.24m Ground Clearance 0.32m Wheel Base 3.80m Performance S.W.L 1800kg Goods 1350kg Max. occupants 4 Turning Radius(Inside/Outside) 3.05/4.34m Turret Rotation ±90° Travel Speed(Stowed) 6.00km/h Travel Speed(Working) 0.90km/h Gradeability 40% Maximum Slope 3°/5° Chassis Leveing 10° Tyre 355/55D 625 Power Engine (Perkins 804D-33T) 62kw/2600rpm Engine Deutz TD 2.9 L4 Option 55.4kw/2600rpm Fuel Diesel Hudraulic Tank 216L Fuel Tank 137L Weight
