Roll-fed thermoforming machine FSCT-820/650 series
ABSPPPS

roll-fed thermoforming machine
roll-fed thermoforming machine
roll-fed thermoforming machine
roll-fed thermoforming machine
roll-fed thermoforming machine
roll-fed thermoforming machine
Add to favorites
Compare this product


Characteristics

Type
roll-fed, PP, PS, ABS
Applications
for cup production
Operational mode
automatic
Film width

Max.: 860 mm
(34 in)

Min.: 0 mm
(0 in)

Maximum depth of draw

Max.: 150 mm
(6 in)

Min.: 0 mm
(0 in)

Forming area x

820 mm
(32 in)

Forming area y

650 mm
(26 in)

Description

The FSCT-820/650 Series adopts the most advanced thermoforming technology. This series combine high output, high quality, high efficiency, low comsumption ,suitable for mass production. Its outstanding stability and superior performance will provide an excellent return. Conform to indicator of hygiene quality and save labor. Feeding and stacking driven by servo motor Mould with rapid change,remember all datum of moulds Intelligently and Automatic electric adjustment More precision temperature control(toerance:±1℃) With automatical testing material droping, heater protecting safety system. Fill oil automatically to lubricate mechanism movement at certain time.
