Plug valve
pneumaticdrainweld

Plug valve - Zhejiang Jieyu Valve Company - pneumatic / drain / weld
Plug valve - Zhejiang Jieyu Valve Company - pneumatic / drain / weld
Plug valve - Zhejiang Jieyu Valve Company - pneumatic / drain / weld - image - 2
Plug valve - Zhejiang Jieyu Valve Company - pneumatic / drain / weld - image - 3
Plug valve - Zhejiang Jieyu Valve Company - pneumatic / drain / weld - image - 4
Add to favorites
Compare this product


Characteristics

Type
plug
Operation
pneumatic
Function
drain
Body
weld, T, Y, stainless steel, cast iron, carbon steel
Applications
flange
Other characteristics
compact, ISO, standard, ANSI, DIN, actuated, socket weld

Description

Compact Flanged Y Type Strainer With NPT Drain Plug ASME B 16.34 Design Product Details: Place of Origin: - Wenzhou China Brand Name: - JIEYU Certification: - API ISO Ts CE Payment & Shipping Terms: Minimum Order Quantity: - 1PC Price: - Negotiable Packaging Details: - Plywood Case Delivery Time: - 7-30 work days Payment Terms: - L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability: - 10000PCS/Mouth Carbon Steel Flanged Y Type Filter Strainer Stainless Steel Wire Meshes Y Strainer with NPT Drain Plug Material of Construction: Cast Iron - : IS 210 Gr FG 200 Cast Carbon Steel - : ASTM A 216 Gr WCB / WCC Cast Stainless Steel - : ASTM A 351 Gr CF 8/CF 8M Forged Carbon Steel - : ASTM A 105 Forged Stainless Steel - : ASTM A 182 Gr F304 / F316 Design & Testing International Standard: Valve Design - : API 594 / API 600(ISO 10434) / API 6D(ISO 14313) / API 602 / API 603 / API 608 / API 609 / IS 780 / BS 1414 / BS 14846 / BS 1868 / BS 1873 / BS 5351 / ASME B 16.34(BS 5351) / DIN 3352 / DIN 3356 / DIN 3357 Pressure Testing - : API 598 / API 600 / API 6D Face To Face - : ANSI B 16.10 End Connection - : Screwed AS PER BSP/BSPT/NPT, Weld AS PER SW/BW, Flange AS PER RF/RTJ Flange Connection - : ANSI B 16.5 (For NPS≤24) / ANSI B 16.47 SERIES B, ANSI 16.47 SERIES A, MSS SP-44 (For NPS >24) Butt Weld End - : ANSI B 16.25 Socket Weld End - : ANSI B 16.11 Screwed End - : ANSI B 1.20.1(BSP/NPT) Wall Thickness - : API 600 / BS 1868 Pressure Rating - : AS PER ANSI 125#, 150#, 300#, 400#, 600#, 800#, 900#, 1500#, 2500# Engineering Option - : Gear Operated, Electrical Actuated, Pneumatic Actuate Size Range - : AS PER NPS 2" - 48"

Other Zhejiang Jieyu Valve Company products

Y Type Strainer
