Differential pressure switch LF55 seriesfor oilfor waterfor air
Add to favorites
Compare this product
Characteristics
- Pressure type
- differential
- Fluid
- for oil, for water, for air
- Applications
- industrial, for pump, for cooling compressors, HVAC
- Pressure range
Max.: 33 bar
(478.62 psi)Min.: -0.5 bar
(-7.25 psi)- Process temperature
Max.: 120 °C
(248 °F)Min.: -10 °C
(14 °F)
Description
LF55 Series pressure switches is usually used with fluorinated refrigerants to control the pressure of compressor in refrigeration system. It can also used in air and water. Internal Micro-swith ensures reliable switching. It is provided standard Mounting Bracket.
Medium - Réfrigérant, Air, Water, Oil
Media Température - -10°C - 120°C
Connection - M12X1.25, 7/16-20UNF other connection is available on request
Contact Arrangement - SPDT
Electrical Rating: - Non-Inductive: 20A@125VAC,10A@ 250 VAC Inductive: FLA:15A@ 125VAC,8A@250VAC LRA:72A@ 125VAC,64A@250VAC
