Digital temperature controller CE, 116x100x22.5 mm, 21 - 48 V | CH3000PIDDIN rail
Add to favorites
Compare this product
Characteristics
- Display
- digital
- Type
- PID
- Other characteristics
- DIN rail
- Maximum temperature
Max.: 50 °C
(122 °F)Min.: 0 °C
(32 °F)
Description
PID DIN-Rail mounting temperature controller& transmitter
Supervised by software on PC through RS485 interface Modbus/RTU protocol.
Universal input for:
Thermocouples( K, J, E, S, B, R, N, T)
RTD’s ( pt100. cu50)
Linear signals( 0/1-5V, 0-20mA, 4-20mA)
Output ( should be defined in order):
Relay / SSR output selectable by jumper
Linear signal output
Retransmission output
0/4-20mA, 0/1-5V
Automatic/ Manual operation.
Auto-tuning
Selectable max output power to load.
Two configurable alarms.
Selectable heating/ cooling control.
Configurable Celsius or Fahrenheit
External digital input.
Thickness: 22.5mm.
