Roller grinding mill YM series
verticalfor limestonelarge

roller grinding mill
roller grinding mill
roller grinding mill
roller grinding mill
roller grinding mill
roller grinding mill
roller grinding mill
Add to favorites
Compare this product


Characteristics

Technology
roller
Orientation
vertical
Product applications
for limestone
Other characteristics
large
Output

Max.: 120 t/h
(73 lb/s)

Min.: 12 t/h
(7 lb/s)

Motor power

75 kW, 110 kW, 160 kW, 200 kW, 250 kW
(101.97 hp, 149.56 hp, 217.54 hp, 271.92 hp, 339.91 hp)

Machine weight

3 t, 6 t, 8 t, 13 t, 19 t
(3 us ton, 7 us ton, 9 us ton, 14 us ton, 21 us ton)

Description

Raw materials: - Limestone, calcium carbide, sandstone, coal gangue, gypsum, blast furnace slag, lump coal Max feeding size: - 40mm Application: - cement, coal crushing, mining, desulfurizing in power plant Shipping ports: - Shanghai, Qingdao or Tianjin Delivery: - 15-30 days The YM series of pre-grinding mill is designed with a simple vertical structure and features hierarchical crushing, easy operation, low energy consumption and little dust. It is without sieve plate so the problem of blocking is eliminated. The hammerhead uses a hinge structure making it convenient for replacement. Both the hammerhead and scaleboard are manufactured with highly wear-resistant alloy and feature high strength, high corrosion resistance and long service life. 1.The granularity of feedstock allowed is large (D≤100mm). 2.The granularity of discharged product is small (D D95≤0.9mm). Discharging efficiency is high. It saves more than 25% of electricity. 3.The process flow is easy. The pre-grinding mill occupies little space and saves on civil engineering investment. 4.The wear resistant part has longer service life.
