Centrifugal appliance fan M113P.D001

coolingsuction

[ High Efficiency ] Composite material impeller optimized by ternary flow CFD fluid simulation technology, reasonably designed flow runner combined with ultra-efficient DC motor create the high efficiency of the fan. [ Low Noise ] The designer closely combines aerodynamics and sound source, and makes the blade angle and blade pattern fully adapt to the ternary flow field, which always ensures lower noise at the same air volume. [ High Reliability ] Motors have F class insulation, and been tested for 3 months of 60℃ high temperature test and 40,000 hours of life test, which ensure worse-free quality. [ Accurate Intelligent Control ] The fan adopts efficient DC motor and supports various control modes such as 0~10V / PWM to accurately meet the ventilation needs of different period of time. [ Wide Application ] The products is used wherever outstanding performance is required, for example, air purifier, bladeless fan and more. [ Variety of Models ] Dimensions: 113mm, this allows for air flow rates of up to 221m3/h and static pressure of up to 300Pa. [ Material ] Impeller:Nylon with Glass Fiber [ Bearing ] Maintenance-free Ball bearings [ Approval ] CCC, CE [ Amb.Temp ] -5~+50℃
