High Performance Poultry and meat weight grading machine
High Performance Poultry and meat weight grading machine manufacturer with factory price
TECHNICAL PARAMETER
Model -
DHWS600*300-8
Sorting product -
Whole chicken/duck
Weight range
(1g-2500g)
Max size:
(400*250*100 mm L*W*H)
Weighing capacity -
2500g
Minimum graduation -
0.01g
Sorting speed -
100 pcs/min
Weighing accuracy -
±3-5g
Weighing belt size -
600mm*300mm (L*W)
Construction -
Waterproof and moisture protection (International standard IP65)
Weighing direction -
From left to right (Facing the operation display)
Weighing sensor -
Germany HBM
Control system -
Dahang (Independent R & D)
Operation display -
8 inches touch screen
Weighing data output -
USB port
Rejecting type -
Flapper rejector
Products parameters -
Can restore and recall 100 products
Belt conveyor -
Food grade white color Belt
Language -
English
Height of conveyor -
750+60mm (Customized)
Power supply -
Single phase AC220V±10%, 50/60HZ
Construction -
SUS304, polishing
Using environment -
High humidity, low temperature
Package -
With plastic film inside and professional export wooden case outside.
HS code -
84232010.00
FEATURES
● 4 parts: manual feeding device, buffering belt, weighing belt and sorting conveyor.
● High accuracy: ±3-5g
● High sorting speed 6000 pcs/min adjustable
● Strong stainless steel 304 structure
● Waterproof and moisture protection, anti - condensation device in electric box. Control board Potting process.
● Reliable and stable weighing and control system
● Weighing data USB port download in Excel sheet.
● Operation display: 8 Inches Color Touch Screen
● Product Storage: 100 products preset.
