DIP switch CNR seriessingle-polelow-torquesnap-action
Add to favorites
Compare this product
Characteristics
- Type
- DIP
- Number of poles
- single-pole
- Other characteristics
- low-torque, snap-action, miniature, electromechanical
- Primary current
Min.: 1 A
Max.: 5 A
- Voltage
Min.: 125 V
Max.: 250 V
Description
Operating Frequency (mechanical).....120 operations / mim
Operating Frequency (electrical).....10~30 operations / mim
Insulation Resistance (at 500VDC).....100M Ω (Min.)
Dielectric Strength (50-60Hz).....1000VAC RMS
Storage Temperature.....-25℃ to 85 ℃
Storage Humidity.....At 40 ℃,Max. 85% RH (Max.)
Service Life (mechanical).....Min. 10000000 operations
Service Life (electrical).....Min. 6000 operations
Application：
TV Game,Vending Machine,Coin-op Phone Pin-Ball Game
