PCI Express CPU board MXM-R1

Rockchip RK3588HDMIDisplayPort

- Support 2GMAC network ports (one is optional for LAN) - MXM slot, support expanding MXM AI acceleration card - Operating temperature: -20℃~55℃, - Size 82*105mm NPU Core 6Tops neural network processing performance, support INT4/INT8/INT16 hybrid operation Memory Clock 2133MHz Speed Model 400MB/s at HS400 mode, dual channel Board Power - Board 4V±5% input Video Encoder - 8K@30fps H.265/H.264 encoding Video Decoder - 8K@60fps H.265/H.264/VP9/AV1 decoding JPEG Encoder - 1080P@280fps JPEG Decoder 1080P@280fps Operating Temperature -20℃~55℃ Storage Temperature -40℃~85℃ Operating Humidity Operation environment: 5%~85% humidity, (0℃~45℃) non condensing Storage Humidity Storage environment: 5%~95% humidity, (-40℃~85℃) non condensing
