Analog Devices stepper motor controllers

Output voltage: 7 V - 34 V
Current: 1.1 A

TMCM-343 is a compact and versatile triple axis 2-phase stepper motor controller and driver module. It provides a complete motion control solution at a very small size ...

... is a slot type microcontroller module that can control up to four ADI Trinamic slot type motor driver modules using TMCL commands. The stepper and/or BLDC motor modules are controlled ...

Output voltage: 11 V - 28 V
Current: 3 A

3-axis stepper motor controller/driver module 11to 28V, 3A, 256 µSteps, with USB, CAN and RS485, RS232 Interface, StallGuard, CoolStep and StealthChop TMCM-3351 is a three axes motor ...

Output voltage: 10 V - 30 V
Current: 1.9 A

The TMCM-6214 is a 6-axes motor controller/driver board for 2-phase bipolar stepper motors with up-to 2A RMS motor current and+24V nom. supply. The motion ...

Output voltage: 9 V - 28.5 V
Current: 1 A

... use 3-axes stepper motor controller and driver unit for embedded applications. It offers CAN bus, UART and USB interfaces for communication and supports stand-alone operation, also. The ...

Output voltage: 11 V - 35 V
Current: 1.1 A

The TMCM-6212 is a sextuple axis stepper motor controller/driver module for sensorless load dependent current control. The device is powered by ADI Trinamic StallGuard2™, CoolStep™, SpreadCycle™, ...

Output voltage: 11 V - 53 V
Current: 3 A

The TMCM-3212 is a triple axis stepper motor controller/driver module for sensorless load dependent current control. The device is powered by ADI Trinamic StallGuard2™, CoolStep™, SpreadCycle™, ...

Output voltage: 9 V - 28 V

The TMCM-6110 is a six-axis stepper motor controller/driver module for sensorless load dependent current control. The device is powered by ADI Trinamic's StallGuard2™, CoolStep™ and SpreadCycle™ ...

Output voltage: 5 V

The TMCM-301 is a triple axis stepper motor controller module for external power drivers with SPI interface. With its very small size it is dedicated to embedded applications. The board ...

Output voltage: 9 V - 52 V
Current: 2.8 A

The TMCM-3110 is a triple axis stepper motor controller/driver module for sensorless load dependent current control. The device is powered by ADI Trinamic StallGuard2™, CoolStep™ and ...
