GE Grid Solutions disconnect switches

VAC: 72,500 V - 550,000 V

The center break grid disconnector known as the Alstrom Grid S2DA, is one of the most commonly used in the world due to its easy, yet effective design in which both insulators open and close the switch. ...

VAC: 25,000 V - 550,000 V

The Alstom Grid CGVB-05 is a vertical break disconnector that will keep phase spacing from being a threat. This works with voltages from 25 to 550 kV and can operate in conditions from -50 to 50 Celsius. This can even ...

VAC: 72.5 kV - 1,000 kV

... the key benefits, high rigidity is guaranteed by the double scissor design, while the manufacturer has also made an earthing switch available. Note that all materials used for manufacturing are corrosion resistant and ...

Primary current: 4,000 A
VAC: 123 kV - 1,000 kV

The SPV disconnector from Alstom works at up to 1000 kV and uses up to 30% less space than other units, because it is a horizontal item instead of a vertical separation unit. This can link a lower busbar to an upper busbar, ...

Primary current: 4,000 A
VAC: 0.14 kV - 1,000 kV

The Alstom Grid SPVL vertical reach disconnector maximizes space utilization by connecting the lower busbar to the upper one via the semi-pantograph arm. It reduces space usage by 30% due to the horizontal rather than ...

Primary current: 4,000 A
VAC: 245 kV - 1,200 kV

The Alstom Grid SPO is a vertical break disconnector with a two-piece arm. In the open position the blade sections fold upon themselves in a vertical plane of only 60% of the longitudinal dimension. Main Characteristics ...

Primary current: 4,000 A
VAC: 245 V - 1,200 V

The Alstom GRID SPOL is very unique of its vertical break disconnector with a 2 piece arm. This is highly flexible because in an open position, the blade sections can fold in a vertical plan of only 60% of the longitudinal ...

VAC: 725 kV - 1,450 kV

... leading manufacturers when it comes of disconnectors and one of its product is the Alstom Grid VCB. This is a unique V-type center break disconnector on which both insulators rotate to open and close ...

VAC: 72.5 kV - 300 kV

... have insulators as well as space saving options. The structure can be configured for 1 or 2 earthing switches operable with interlocking key and disconnector blade systems or mechanically. The grid can ...

VAC: 72.5 kV - 550 kV

The Alstom Grid S3CD is a double side break disconnector on which the centre insulator rotates to open and close the switch, and is particularly suitable for installations with low vertical clearance. Main ...
