Haydon Kerk actuators

Stroke : 305 mm
Force: 67 N
Torque: 1.7 Nm

NEW! Performance in an Ultra-Compact 2-axis Design. Designed for easy integration in OEM assemblies, the Haydon Kerk Z-Theta offers linear + rotary point to point motion in an compact footprint. Unlike in-house component-up designs requiring ...

Stroke : 9 mm - 200 mm
Force: 2 N - 45 N

The Size 8 by Haydon Kerk Motion Solutions is a 21mm stepper motor linear actuator. Size 8, 21000 series linear actuators are available in three designs - captive, non-captive and external linear versions. ...

Stroke : 12.7 mm - 250 mm
Force: 15 N - 90 N

The Size 11 by Haydon Kerk Motion Solutions is a 28mm stepper motor linear actuator. Size 11, 28000 series linear actuators are available in three designs - captive, non-captive and external linear versions. ...

Stroke : 12.7 mm - 250 mm
Force: 30 N - 133 N

The Size 11 double stack by Haydon Kerk Motion Solutions is a 28mm stepper motor linear actuator. Size 11, 28000 double stack series linear actuators are available in three designs - captive, non-captive ...

Stroke : 12.7 mm - 300 mm
Force: 50 N - 220 N

The 35000 series by Haydon Kerk Motion Solutions is a linear stepper actuator which is designed to provide higher force, longer life and improved performance. It comes with different patent pending designs that has an ...

Stroke : 12.7 mm - 300 mm
Force: 50 N - 220 N

The Size 14 double stack by Haydon Kerk Motion Solutions is a 35mm stepper motor linear actuator. Size 14, 35000 double stack series linear actuators are available in three designs - captive, non-captive ...

Stroke : 12.7 mm - 400 mm
Force: 100 N - 200 N

The Size 17 by Haydon Kerk Motion Solutions is a 43mm stepper motor linear actuator. Size 17, 43000 series linear actuators are available in three designs - captive, non-captive and external linear versions. ...

Stroke : 12.7 mm - 400 mm
Force: 50 N - 350 N

The Size 17 double stack by Haydon Kerk Motion Solutions is a 43mm stepper motor linear actuator. Size 17, 43000 double stack series linear actuators are available in three designs - captive, non-captive ...

Stroke : 12.7 mm - 500 mm
Force: 300 N - 880 N

... size 23 stepper motor linear actuator by Haydon™ comes in captive, non-captive, and external linear versions. This unit integrates similar optimum performance and stable structures as the size 17. This linear actuator ...

Stroke : 12.7 mm - 500 mm
Force: 150 N - 880 N

The Haydon™ Size 23 double stack stepper motor linear actuator is available in captive, non-captive, and external linear options. It incorporates the same high performance and durable patent pending design as the size ...
