PILZ voltage monitoring relays

... Applications: Suitable for basic functions Safety relay PNOZ c1 – Monitor an E-STOP or safety gate – in any application – safe, simple, yellow. Use one safety relay per safety function. The safety ...

Trigger voltage: 24 V - 240 V

... Insulation monitoring: The insulation monitor PMD s20 can be used to monitor the insulation resistance of unearthed AC/DC systems. Thanks to the separate supply voltage, monitoring ...

Trigger voltage: 0 V - 500 V

... electronic monitoring relays! Whether for monitoring voltage, phase sequence, current, insulation, true power, temperature, standstill or fault voltage, ...

Tripping current: 1 A - 12 A
Trigger voltage: 24 V - 240 V

True power monitoring device for measuring and monitoring the true power of electrical loads, limit values that can be set via display, can be saved to chip card,relay output: 2 changeover ...

Trigger voltage: 24 V - 240 V

Insulation monitor, Sigma housing, for monitoring the insulation in galvanically isolated networks, limit values can be setvia display, can be stored on a chip card, relay output: 2 switching contacts, ...

Trigger voltage: 24 V

Voltage monitoring relay, to monitor min. and max. voltage values, 12 measuring ranges 0.1 - 500 V AC/DC selectable, 0.40 -400 Hz, width = 22.5 mm, UB = 24 V DC. General ...

Trigger voltage: 24 V

Voltage monitoring relay, to monitor overvoltage and undervoltage values, and the phase sequence in 3-phase supplies, 40 -400 Hz, measuring voltage 400/440 V AC, width ...

Tripping current: 0.01 A - 15 A
Trigger voltage: 230, 240 V

Voltage monitoring relay, to monitor max. current values, 12 measuring ranges 0.01 - 15 A selectable, 0, 40 - 400 Hz, width = 22.5mm, UB = 230 - 240 V AC. General data Approval - ...

Trigger voltage: 120, 240 V

Voltage monitoring relay, to monitor min. and max. voltage values, 0.40 - 400 Hz, measuring voltage 1 V AC/DC, width = 22.5 mm, UB = 24 V AC/DC, 120/240 ...

Trigger voltage: 24 V - 240 V

Fault voltage monitoring of welding transformers to VDE 0545, 6 measurement input circuits 0 - 690 V AC/DC, 50 Hz - 1 kHz, responsevoltage 24 V AC/DC, width 45 mm, UB = 24 - 42 V AC, 42 - 240 V DC. General ...
