Dimetix AG

Dimetix has been developing and manufacturing laser distance sensors for more than 20 years. As a company that is proud of being Swiss, we aim for the highest possible quality, resulting in unique, accurate long-distance sensors - the solution that provides applications for the most accurate demands for measurement.

With Dimetix, even your most challenging applications can be realized due to our technical application support available to all our customers.

Our products measure distances of up to 500 meters, with an accuracy of ±1 millimeter.

Each sensor includes the majority of features, so selecting the sensor that is right for you is easy.

Sensors are always available in stock, which guarantees the shortest delivery times.

Highlights of the Dimetix Laser Distance Sensors are precision, robustness, flexibility and speed. Our Laser Distance Sensors measure over the complete measuring range with an accuracy of 1 mm and with a repeatability of 0.3 mm. The measuring range is between 0 and 500 meters. The devices work with a measuring rate up to 250 Hz and have an output rate up to 1 kHz.

Due to many years of innovations and continuous development, Dimetix Laser Distance Sensors work under arduous external conditions. It is possible to even measure on black surfaces with solar irradiation. Extreme working temperatures from – 40 up to + 60 °C and a solid metal case help them withstand the hardest environments.

The Dimetix Laser Distance Sensors are equipped with a multitude of serial interfaces as standard. Besides synchronous and asynchronous interfaces, PROFINET, EtherNet/IP, EtherCAT and PROFIBUS are also available.

An analogue 0/4...20 mA output and digital in- and outputs are standard. While the serial interfaces as well as further features can be configured by the customer.
